Martin Audio WPL debuts at Brockwell Park

Solotech returned to Brockwell Park in South London recently - for three successive weekends of festival activity - fielding their flagship Martin Audio WPL on main stage for the first time. After populating the event in previous years with Martin Audio MLA, they thought it was time for an upgrade to their recently expanded WPL inventory.

This provided site coverage for a variety of events that included Wide Awake, Field Day, Cross The Tracks, City Splash, Mighty Hoopla and Lambeth Country Show over the long duty cycle. The Festival site attracted an aggregate of more than 300,000 people in all, and Solotech - working alongside production manager Frankie Tee of Enteetainment and technical production manager Amy Harmsworth - fielded 62 WPL elements on main stage, driven in 1-box resolution from Martin Audio’s multi-channel iKon iK42 DSP amplifiers.

The main hangs comprised sixteen elements per side; side hangs were split six WPL (stage left) and twelve WPL (stage right), while the final twelve WPL modules formed a single central delay hang. The second delay tower deployed in previous years, was deemed unnecessary, due to WPL’s throw capability. Further boosting the sound were eighteen SXHF218 in a castellated broadside cardioid sub-array, with frontfills comprising twelve Martin Audio WPC and four XD12.

Moving from the second stage last year to main stage system tech duties was Ali Hellard, who has extensive experience working with WPL. It was his task to optimise the sound and ensure there were no offsite breaches while maintaining levels at FOH. “It’s a tricky site, and so we needed that 1-box control because we were moving from MLA to WPL, which is really good at steering audio”, notes Solotech account manager David Preston. Hellard confirms that with eight stages (plus fairground rides) the site needed to be heavily monitored for sound escape, with around seven measurement points around the perimeter. Onsite limits were set at 103 dB (C-weighted) for morning slots, 105 dB(C) for afternoon and early evening and headliners 108 dB(C).

Hellard observed that the reggae-oriented City Splash presented the biggest challenge in view of the heavy demand on LF. To that end the castellated sub array approach was his chosen option. “Tonally, I tend to prefer arranging them in stacks of three with one reversed”, he says. “However, on a sensitive site, castellated is much better from a pattern control point of view.” The cardioid also helped mitigate noise propagation behind the PA, where it was needed with that entire area designated Hard Avoid in the Martin Audio software, a proprietary feature that actively reduces direct sound and sound leakage to an area by up to 30 dB.

Brockwell Park main stage audio crew also included Tim Paterson, Tom Woolsey, Kieran Niemand, Dave Pickess, Luan Nikita, Isabella Di Biase, Tim Grasse, and Elliot Heal.

(Photos: Martin Audio/Solotech)
